CHANNEL 150x2000 CENTER OUTLET - (670CH020-10BA)
×
![]()
Part Of the Series: Channel-No membrane
Type no.: 670CH020-10BA
EAN no.: 5705499129441
NRF no.: 3397068
Size: 150x2000
CHANNEL 150x2000 CENTER OUTLET
-Floor: concrete, tiled and resin
-No membrane
-Outlet: Ø110mm, vertical
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Field of Application | Industrial |
| Floor | Concrete / Tiled / Resin |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Membrane Type | No Membrane |
| Minimum Height (mm) | 152 |
| Outlet Box | No |
| Outlet dia. (Inch) | 4 |
| Outlet Diameter (mm) | 110 |
| Outlet Direction | Vertical |
| Outlet Placement | Center |
| Shape | Rectangular |
| Size (Inch) | 5⅞x78¾ |
| Size (mm) | 150x2000 |
| Weight (kg) | 12,26 |
| Weight (lbs) | 27,03 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
HACCP Food Safety Programme - Europe
AUS - WMKT00204 - 24
TÜRK LOYDU - 25041616077231247
NO - PS3079
US - NSF ABS - 23-2329630-PDA Lloyds Register LR22419510TA_02 DNV - TAP0000023-rev5, Sanitary discharge pipes RINA -MAC320524XG EuroPipe PL - Hygienic Certificate - All Products KR - Type Approval CPH42135-PE001
