CHANNEL 200x1500 CENTER OUTLET - (674DH015-08BA)

Part Of the Series: Channel-Liquid membrane

Type no.: 674DH015-08BA

EAN no.: 5705499130966

Size: 200x1500

Product Specification
Field of Application Industrial
Floor Concrete / Tiled / Resin
Material AISI 304
Material (EN) EN 1.4301
Membrane Type Liquid Membrane
Minimum Height (mm) 152
Outlet Box No
Outlet dia. (Inch) 4
Outlet Diameter (mm) 110
Outlet Direction Vertical
Outlet Placement Center
Shape Rectangular
Size (Inch) 7⅞x59
Size (mm) 200x1500
Weight (kg) 14,07
Weight (lbs) 31,02
