CHANNEL 150x5000 END OUTLET - (671CK050-00BA)
Part Of the Series: Channel-No membrane
Type no.: 671CK050-00BA
EAN no.: 5705499130102
Size: 150x5000
CHANNEL 150x5000 END OUTLET
-With outlet box
-Floor: concrete, tiled and resin
-No membrane
-Outlet: Ø160mm, vertical
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Industrial |
Floor | Concrete / Tiled / Resin |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | No Membrane |
Minimum Height (mm) | 205 |
Outlet Box | Yes |
Outlet dia. (Inch) | 6 |
Outlet Diameter (mm) | 160 |
Outlet Direction | Vertical |
Outlet Placement | End |
Shape | Rectangular |
Size (Inch) | 5⅞x196⅞ |
Size (mm) | 150x5000 |
Weight (kg) | 32,94 |
Weight (lbs) | 72,62 |
-
