SHOWER CHANNEL WATERLINE 800 - (275.080.056.20)
×
![]()
Part Of the Series: Shower channel-Vinyl
Type no.: 275.080.056.20
EAN no.: 5705499122534
VVS no.: 155060008
RSK no.: 7121680
NRF no.: 3394732
Size: 50x800
SHOWER CHANNEL WATERLINE 800
-Floor: vinyl
-Frame: rectangular
-Outlet: Ø50mm, vertical
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Field of Application | Domestic |
| Floor | Vinyl |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Minimum Height (mm) | 128 |
| Outlet Box | No |
| Outlet dia. (Inch) | 2 |
| Outlet Diameter (mm) | 50 |
| Outlet Direction | Vertical |
| Outlet Placement | End |
| Shape | Rectangular |
| Size (Inch) | 2x31½ |
| Size (mm) | 50x800 |
| Weight (kg) | 2,61 |
| Weight (lbs) | 5,75 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
TÜRK LOYDU - 25041616077231247
HACCP Food Safety Programme - Australasia
DK - MK 7.21/1664
DK - VA 2.44/19205
BLÜCHER® Drains EPD
SE - RI.SE 0084-07 2021 Type 275, 398
FI - Tyyppihyväksyntäpäätös EUF129-23001919-TH2 DNV - TAP0000023-rev5, Sanitary discharge pipes RINA -MAC320524XG EuroPipe Declaration of Conformity - EN1253-001 Lloyds Register LR22419510TA_02 PL - Hygienic Certificate - All Products ABS - 23-2329630-PDA Declaration of Conformity - BSEN1253-002
