CHANNEL 300x5000 END OUTLET - (670EK050-00BA)
Part Of the Series: Channel-No membrane
Type no.: 670EK050-00BA
EAN no.: 5705499129885
Size: 300x5000
CHANNEL 300x5000 END OUTLET
-Floor: concrete, tiled and resin
-No membrane
-Outlet: Ø160mm, vertical
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Industrial |
Floor | Concrete / Tiled / Resin |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | No Membrane |
Minimum Height (mm) | 200 |
Outlet Box | No |
Outlet dia. (Inch) | 6 |
Outlet Diameter (mm) | 160 |
Outlet Direction | Vertical |
Outlet Placement | End |
Shape | Rectangular |
Size (Inch) | 11¾x196⅞ |
Size (mm) | 300x5000 |
Weight (kg) | 43,66 |
Weight (lbs) | 96,25 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
