HYGIENICPRO CHANNEL 150x9000 CENTER OUTLET - (676CT090-45CF)
Part Of the Series: Channel-No membrane
Type no.: 676CT090-45CF
EAN no.: 5705499137606
VVS no.: 221801390
LVI no.: 3305733
Size: 150x9000
HYGIENICPRO CHANNEL 150x9000 CENTER OUTLET
-Low model. With outlet box
-Floor: concrete, tiled and resin
-No membrane
-Outlet: Ø110mm, horizontal
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Industrial |
Floor | Concrete / Tiled / Resin |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | No Membrane |
Minimum Height (mm) | 319 |
Outlet Box | Yes |
Outlet dia. (Inch) | 4 |
Outlet Diameter (mm) | 110 |
Outlet Direction | Horizontal |
Outlet Placement | Center |
Shape | Rectangular |
Size (Inch) | 5⅞x354⅜ |
Size (mm) | 150x9000 |
Weight (kg) | 62,68 |
Weight (lbs) | 138,19 |
-
