SWEPT BRANCH 87.5° - (839.160.160 S)
Part Of the Series: Swept branch-87.5-long bend
Type no.: 839.160.160 S
EAN no.: 5705499402667
VVS no.: 160222460
RSK no.: 1550389
NRF no.: 2170803
LVI no.: 0255245
SWEPT BRANCH 87.5°
-Pipe diameter: Ø160mm. Branch diameter: Ø160mm
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Angle (°) | 87.5 |
Length (mm) | 331 |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Outlet dia. (Inch) | 6 |
Outlet Diameter (mm) | 160 |
Weight (kg) | 4,52 |
Weight (lbs) | 9,96 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
HACCP Food Safety Programme - Australasia DK - VA 2.12/19349 EuroPipe DS432 US - IAPMO File No.3247-EuroPipe DK - VA 2.12/19350 NO - 0692-22 EuroPipe HACCP Food Safety Programme - Europe DNV - TAP0000023-rev4, Sanitary discharge pipes MARINE - R4547 NATO CODIFICATION SYSTEM UR - 1055745 Product approval, EuroPipe and Drains ABS - LD1716353-PDA PL - Hygienic Certificate - All Products Achilles Certificate - 46702-22 Lloyds Register LR22419510TA KR - Type Approval CPH42135-PE001 RU - 0212322 Pipes-21 Bureau Veritas, 02375-I0 Pipes & Fittings RINA -MAC285119XG EuroPipe
