SWEPT BRANCH 87.5° - (839.110.110 S)
Part Of the Series: Swept branch-87.5-long bend
Type no.: 839.110.110 S
EAN no.: 5705499402629
VVS no.: 160222410
RSK no.: 1550387
NRF no.: 2170801
LVI no.: 0255240
SWEPT BRANCH 87.5°
-Pipe diameter: Ø110mm. Branch diameter: Ø110mm
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Angle (°) | 87.5 |
Length (mm) | 236 |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Outlet dia. (Inch) | 4 |
Outlet Diameter (mm) | 110 |
Weight (kg) | 1,64 |
Weight (lbs) | 3,62 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
NO - 0692-22 EuroPipe DK - VA 2.12/19349 EuroPipe DS432 HACCP Food Safety Programme - Australasia HACCP Food Safety Programme - Europe DK - VA 2.12/19350 US - IAPMO File No.3247-EuroPipe KR - Type Approval CPH42135-PE001 UR - 1055745 Product approval, EuroPipe and Drains Lloyds Register LR22419510TA Achilles Certificate - 46702-22 RU - 0212322 Pipes-21 MARINE - R4547 NATO CODIFICATION SYSTEM Bureau Veritas, 02375-I0 Pipes & Fittings DNV - TAP0000023-rev4, Sanitary discharge pipes PL - Hygienic Certificate - All Products RINA -MAC285119XG EuroPipe ABS - LD1716353-PDA
