DOUBLE BRANCH 87.5° - (831.110.110)
Part Of the Series: Double branch-87.5-180
Type no.: 831.110.110
EAN no.: 5705499401882
VVS no.: 160231110
RSK no.: 1550174
NRF no.: 2172345
LVI no.: 0244160
DOUBLE BRANCH 87.5°
-Pipe diameter: Ø110mm. Branch diameter: Ø110mm
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Angle (°) | 87.5 |
| Length (mm) | 183 |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Outlet dia. (Inch) | 4 |
| Outlet Diameter (mm) | 110 |
| Weight (kg) | 1,14 |
| Weight (lbs) | 2,51 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
FR - DTA 14.1/12-1811*V2 EuroPipe
AUS - WMKT00204 - 18B
US - IAPMO File No.3247-19
DK - VA 2.12/19349-19
NO - 0692-22 RU - 0212322 Pipes-21 ABS - 18-LD1716353-PDA PL - Hygienic Certificate - All products MARINE - R4547 NATO CODIFICATION SYSTEM RINA -MAC285119XG EuroPipe DNVGL - TAP0000023-rev2 Achilles Certificate - 25316-21 Lloyds Register 92-00041 (E7) UR - 1055745 Bureau Veritas, 02375-H0 RS - 22.10018.262 KR - Type Approval CPH42135-PE001
